EB6200 High-Temp Epoxy Tooling Board (“300°F Epoxy Board”)
The EB6200, available in 2, 4, and 6 inch x 24” x 60” has been developed to meet the needs of those in the aerospace, motorsport, and automotive industries.

Product Features:
Color Blue
Hardness Shore D 72 ASTM D-2240
Density g/cm 3 (lbs/ft3) 0.64 (40) ASTM D-792
Heat Deflection Temperature ºF 275 ASTM D-648
Glass Transition Temperature ºF >305 ASTM D-3418
Coefficient of Thermal Expansion in/in/ºF 19.4 x 10 -6 TMA

                                                             in/in/°C 35x 10 -6 TMA
Izod Impact, Notched (Un-notched) ft-lbs/in 0.56 (1.05) ASTM D-256

MODELING AND TOOLING BOARDS

MB1100 Polyurethane Foam Tooling Board (10 PCF)
MB1100 is an olive-colored, rigid, closed-cell polyurethane foam tooling and modeling board. MB1100 is low-density foam of approximately 10 lbs/ft3 board. Easily cut using CNC machining equipment or by hand, the MB1100 is perfectly suited for temporary master models, architectural design models, and foundry patterns, as well as design verification and prototype tools.

Product Features:
Density (lbs/ft3): 10

Hardness (Shore D): 20

Tensile Strength (psi): 350

Flexural Strength (psi): 380

Service Temp. (min/max): -300/+195

Compressive Strength (psi): 280

CTE (in./in./°F): 33 x 10-6

Sizes: 2″, 4″, 6″, 8″x24″, 48″x96″-256

MB1150 Polyurethane Foam Tooling Board (15 PCF)
MB1150 is an avocado-colored, rigid, closed-cell polyurethane foam tooling and modeling board. MB1150 is low-density foam of approximately 15lbs/ft3 board. Easily cut using CNC machining equipment or by hand, the MB1150 is perfectly suited for temporary master models, architectural design models, and foundry patterns, as well as design verification and prototype tools.

Product Features:
Density (lbs/ft3): 15

Hardness (Shore D): 30

Tensile Strength (psi): 600

Flexural Strength (psi): 780

Service Temp (min/max): -300/+195

Compressive Strength: 560–590

CTE (in./in./°F): 33 x 10-6

Sizes: 2″, 4″, 6″, 8″x24″, 48″x96″

MB1200 Polyurethane Foam Tooling Board (20 PCF)
MB1200 is a rigid, closed-cell, polyurethane foam tooling and modeling board, with low-density foam of approximately 20lbs/ft3 board. Easily cut using CNC machining equipment or by hand, the MB1200 is perfectly suited for temporary master models, architectural design models, and foundry patterns, as well as design verification and prototype tools.

Product Features:
Density (lbs/ft3): 20

Hardness (Shore D): 40

Tensile Strength (psi): 895

Flexural Strength (psi): 1,330

Service Temp (min/max): -300/+195

Compressive Strength: 1,140–1,130

CTE (in./in./°F): 33 x 10-6

Adhesive: DP-11-83

Sizes: 2″, 4″, 6″, 8″x24″, 48″x96″

MB1300 Polyurethane Foam Tooling Board (31 PCF)
MB1300 is a mahogany-colored, rigid, closed-cell, polyurethane foam tooling and modeling board with medium-low density foam of approximately 30lbs/ft3 board. Easily cut using CNC machining equipment, the MB1300 is perfectly suited for visual master models and architectural design models, as well as design verification and prototype tools.

Product Features:
Density (lbs/ft3): 31

Hardness (Shore D): 58

Tensile Strength (psi): 1,250

Flexural Strength (psi): 2,400

Service Temp (min/max): -300/+195

Compressive Strength: 2,200

CTE (in./in./°F): 33 x 10-6

Color: Mahogany

Adhesive: Dp-11-88

Repair: BC4578

Sizes: 2″, 3″, 4″, 6″x24″, 48″x60″

MB2001 Model and Tooling Plank
MB2001 is a dense, highly machineable, dimensionally stable, tooling plank for today’s CNC machining applications. An advancement over similar products on the market, MB2001 yields low dust emission during machining, is less abrasive to CNC cutters, and provides a highly defined surface finish.

Product Features:
Density(lbs/ft3; gms/cm3): 46.5/74

Hardness: 68D Tg (°F): 172

Tensile strength: 3,800

CTE (in/in/°F): 4.68×10-6

Color: Mahogany (Brown)

Adhesive: DP-11-88

Repair: BC4578

Sizes: 2″, 3″, 4″x16″x60″; 1″, 2″, 3″, 4″, 6″x24″x60″

MB3500 Fixture Plank
We offer a revolutionary, state-of-the-art, machinable, fixture plank for today’s demanding tooling requirements. MB3500 is an extremely tough, high-impact urethane plank that can replace aluminum and other metals for many foundry applications.

Product Features:
Density(lbs/ft3; gms/cm3): 48/77

Hardness: 73D Tg (°F): 215

Heat Distortion (°F): 200

CTE (in/in/°F): 29.00×10-6

Color: Lt. Gray

Adhesive: BC5003 Clear

Repair: BC4570

Sizes: 2″-4″x16″x60″, 1″-6″x24″x60″

MB5000 High Density Tooling Plank
We offer a revolutionary state-of-the-art, machineable, high-density board for today’s demanding tooling requirements. MB5000 is an extremely tough, high-impact, urethane plank that can be used for metal forming as well as nickel plating mandrels.

Product Features:
Density(lbs/ft3; gms/cm3): 100/1.6

Hardness: 88D +2

Heat Distortion (°F): 195 Tg (°F): 215

CTE (in/in/°F): 2.29×10-5

Color: White

Adhesive: BC5003 Clear

Sizes: 1″, 2″, 3″x24″x60″

MB4000 Foundry Plank
We offer a revolutionary, state-of-the-art, machineable, foundry plank for today’s demanding tooling requirements. MB4000 red is an extremely tough, high-impact urethane plank that can replace aluminum and other metals in many foundry applications.

Product Features:
Density(lbs/ft3; gms/cm3): 71/1.14

Hardness: 86D Tg (°F): 240

Heat Distortion (°F): 214

CTE (in/in/°F): 35.60×10-6

Color: Red

Adhesive: BC5003

Red Repair: DP-11-75

Sizes: 2″-4″x16″x60″, 1″-6″x24″x60″

MB8250 Aluminum Tooling Plank
We offer a truly metal-like machineable modeling plank for today’s demanding applications. MB8250 is an aluminum-filled product that is dimensionally stable and exhibits unsurpassed machinable properties. The BC8250 tooling plank will show a significant savings on billet aluminum tooling materials.

Product Features:
Density(lbs/ft3; gms/cm3): 99.84/1.60

Hardness: 85D

Heat Distortion (°F): 175

CTE (in/in/°F): 39.239×10-6

Color: Dark Gray

Adhesive: BC5003 Clear

Sizes: 2″, 3″x16″x60″
